1.1.8 Levelogger Junior Edge

solinst levelogger junior water level dataloggers

The Levelogger Junior Edge provides an inexpensive alternative for measuring groundwater and surface water levels and temperature.


Solinst recommends using the most recent Levelogger Junior Edge firmware version with the latest Levelogger Software version. See Section 2.3.


Levelogger Junior Edge Technical Specifications
Level Sensor: Piezoresistive Silicon with Hastelloy Sensor
Ranges: 5, 10 m
Accuracy: ± 0.1% FS
Normalization: Automatic Temperature Compensation
Temp Comp. Range: 0ºC to 40ºC
Temperature Sensor: Platinum Resistance Temperature Detector (RTD)
Accuracy: ± 0.1ºC
Resolution: 0.1ºC
Battery life: 5 years (based on 1 reading/minute)
Clock Accuracy (typical): ± 1 minute / year (-20ºC to 80ºC)
Operating Temperature: -20ºC to 80ºC
Memory: Continuous or Slate mode
Maximum # Readings: 40,000 sets of readings
Com Interface: Optical Infra-red: USB, RS-232, SDI-12
Communication Speed: 9600 bps
Size: 7/8" x 5.6" (22 mm x 142 mm)
Weight: 4.2 oz (119 grams)
Wetted Materials: Delrin®, Viton®, 316L Stainless Steel, Hastelloy
Sampling Mode: Linear, Future Start, Real Time View
Measurement Rates: 0.5 seconds to 99 hours
Barometric Compensation: High accuracy, air-only, Barologger Edge


Models Full Scale (FS) Accuracy Resolution
M5 5 m (16.4 ft.) ± 0.6 cm (0.020 ft.) 0.02% FS
M10 10 m (32.8 ft.) ± 1.0 cm (0.032 ft.) 0.01% FS
